P6223 Desktop

The P6223 desktop is based on domestic CPU, adopts dual-channel DDR5 high-speed memory design, and is equipped with NVMe SSD. The product uses a 9-liter vertical small chassis, the appearance is simple and fashionable. The system adopts domestic independent security firmware, supports domestic operating system, adaptes to domestic browser, domestic office software, audio and video playback software, graphics processing and other mainstream upper-layer application software, and meets users' daily office, OA, transaction processing and other needs.

  • High performance processor

    Domestic independent research and development of 8-core high-performance processor, the main frequency up to 2.5GHz. Low energy efficiency at the same time to bring a new pleasant feeling, to help more complex application scenarios.

  • Support domestic system

    Rich ecology, support 2000+ domestic software into mobile, cloud enabled, with higher security and stability.

  • Quiet design small size

    9L small case, quiet design small size, can be placed on the desktop, beautiful and versatile.

Application scenario

  • Design Company
    Upgrade core independent graphics card, easily cope with picture modification, video editing work

  • Government Agencies
    Equipped with domestic chips, compatible with domestic operating systems, with high security and stability

  • Financial System
    Can expand HDMI and VGA interface, three screen work more efficient

  • Energy System
    With 6 USB interfaces and 2 TYPE-C interfaces, resource interaction is more simple and convenient

  • Telecommunication System
    Certification, built-in WIFI, safer and more convenient
  • 1
  • 2
Technical specification
Name Specifications
Processor ARM Multi-Core Processor (8Core/2.5GHz)
Memory Support DDR5, expandable up to 64GB
Storage M.2 Port 512GB SSD, compatible with 2242, 2280 models, expandable to 2TB
One 2.5-inch mechanical hard disk and one 3.5-inch mechanical hard disk
Display Support PCIE half-height half-length graphics card, video memory can be optional 1G~4G
External display interface Video card output 1 HDMI output interface; 1 VGA output port
Network interface 1 Gigabit electrical port (RJ45), 1000/100/10Mbps, support network wake-up
USB interface Six USB3.0 ports (Type A) rear
Two USB3.0 ports (Type A) front
Two USB2.0 ports (Type A) front
One USB3.0 port (Type C) front
Serial port Support 9-pin RS232 serial port
Audio interface A front headphone jack and a microphone port
Rear audio interface *3 (output/input/microphone)
Expansion interface Reserved extension WIFI6& BT5.0, antenna built-in
PCIE expansion port One PCIE x16 port
One PCIE x8 port
One PCIE x4 port
All pcie x16 ports support PCIE4.0 and all X16 ports support PCIE5.0
Power supply Up to 350W TFX power supply
Dimensions (length × Width × Height) mm 341mm× 92mm× 290mm
Working ambient temperature 0℃~+40℃
Working humidity 10 ~ 90%RH, non-condensing;
